Trianglelab AL-DDB-Air Cooled Direct Drive Extruder hotend DDB upgrade kit for ENDER-3 Ender 3 CR-10 series 3D printer
Limited Offer!
0.0 (0 Reviews)
$61.90 $55.28 6% OFF
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • size:
    12V AL-DDB-AIR
    24V AL-DDB-AIR
    12V MotorAL-DDB-AIR
    24V MotorAL-DDB-AIR
    SET5 For CR-10S
    SET6 For CR-10S PRO
    SET7 For Ender-3
Quantity
-
+
  • Description
Note
All products purchased on this website are not include tax, including and not limited to: Consumption tax, Value added tax, customs duties, etc,
Before placing an order, please check your country's policies and regulations on online shopping taxes.

The amount you pay does not include tax and you will need to pay it yourself.
To purchase a tax-included products, please click the link below:
https://trianglelab.aliexpress.com/store/1654223

warning:
Please check the instructions provided before purchasing. In the case of side mounting, an adapter plate is required. You can purchase it in the store or modify it with 3D prints. You can have different installation methods.

Introduction:

trianglelabAL-DDB Extruder is a powerful dual drive reductionextruder and hotend combine into one Universal extruder-hotend.

Highlight:

·The extruder body is made ofaluminum alloy and nylon plastic 20% lighter compare to the full aluminum product.
·By combining a hot end and extruder, it is ultra compact. It offers you an extra 25mm of Z-axis build height compared to a V6 + DDB combo.
·Direct feed setup It offers you very high filament compatibility, including flexible filament etc.
·Inherited all the advantage of the DDB extruders powerful yet very reliable.
·Copper heatsink for quicker heat dispersion.
·It offers you all the common type auto bed leveling sensor mounting ability, including M8/12/18 proximity/inductive sensor and very poplar BL-touch.
·It offers you perfect layer fan mount and fan duct not only install for the standard heater block but also able to compatible with volcano heater block.
·It is compatible with ecosystem so you can choose all the type of nozzles and heater blocks to suit your need.
·We offer solution for install this extruder-hotend to the poplar ENDER/CR printers.

▉Installation tutorial & STL

https://drive.google.com/drive/folders/1BjoelM3Kjxd4cWHJL_vv51qZLycvmr0E?usp=sharing

100% TESTED:
1.Because We test all units before shipping, therefore, the accessories you receive may leave traces of installation. This is not because you have received the old item. This is the trace of our employees when testing the product for you.
2.The copper radiator has been fixed in the DDB extruder. Do not use tools to shake or destroy it.

Compatible:
Ender 3
CR-10
And similar machines.
*Installing this module requires you to modify your machine yourself.
If you don't want to do it yourself. Please purchase our metal adapter base.
*CR-10S PRO Need to modify the bracket, please refer to our dimension drawing. You can design your own STL drawings. Modify the installation method.

What's in the box:
SET1: 12V AL-DDB-Air Kit
-12V AL-DDB-Air Kit X 1
-V6 NOZZLE 0.4MM/1.75MM          X 1
-V6 Heat Block                             X 1
-All Metal V6 Heat break               X 1
-fan                                            X 2
-Heating Cartridge (12v 40W)        X 1
-Thermistor cartridge (104GT-2)    X 1
-Thermistor cartridge (100K 3950) X 1
SET2: 24V AL-DDB-Air Kit
-24V AL-DDB-Air Kit X 1
-V6 NOZZLE 0.4MM/1.75MM        X 1
-V6 Heat Block                           X 1
-All Metal V6 Heat break              X 1
-fan                                           X 2
-Heating Cartridge (24v 40W)       X 1
-Thermistor cartridge (104GT-2)    X 1
-Thermistor cartridge (100K 3950) X 1
SET3: 12V AL-DDB-Air ALL Kit
-12V AL-DDB-Air Kit                     X 1
-Nema17-23MM stepper motor      X 1
-V6 NOZZLE 0.4MM/1.75MM         X 1
-V6 Heat Block                            X 1
-All Metal V6 Heat break              X 1
-fan                                           X 2
-Heating Cartridge (12V 40W)       X 1
-Thermistor cartridge (104GT-2)    X 1
-Thermistor cartridge (100K 3950) X 1
SET4: 24V DDB ALL Kit
-24V AL-DDB-Air Kit                      X 1
-Nema17-23MM stepper motor       X 1
-V6 NOZZLE 0.4MM/1.75MM          X 1
-V6 Heat Block                             X 1
-All Metal V6 Heat break                X 1
-fan                                            X 2
-Heating Cartridge(24V 40W)        X 1
-Thermistor cartridge (104GT-2)    X 1
-Thermistor cartridge (100K 3950) X 1
SET5:  AL-DDB-Air Kit For CR-10S
-12V AL-DDB-Air Kit                     X 1
-V6 NOZZLE 0.4MM/1.75MM         X 1
-V6 Heat Block                            X 1
-All Metal V6 Heat break               X 1
-fan                                           X 2
-Heating Cartridge (12V 40W)       X 1
-Thermistor cartridge (104GT-2)    X 1
-Thermistor cartridge(100K 3950)X 1
-Extra spare parts
-Customized cable
-Aluminum Base Adapter
*You can continue to use your own stepper motor. You can also purchase our NEMA17 23MM stepper motor, please click here to buy。
SET6:  AL-DDB-Air Kit For CR-10S PRO
-24V AL-DDB-Air Kit                     X 1
-V6 NOZZLE 0.4MM/1.75MM         X 1
-V6 Heat Block                            X 1
-All Metal V6 Heat break              X 1
-fan                                           X 2
-Heating Cartridge (24V 40W)       X 1
-Thermistor cartridge (104GT-2)   X 1
-Thermistor cartridge(100K 3950) X 1
-Extra spare parts
-Customized cable
-Aluminum Base Adapter
-CR-10S PRO Adapter (There is a hole that cannot be installed, but this does not affect the normal operation of the accessory.)
*You can continue to use your own stepper motor. You can also purchase our NEMA17 23MM stepper motor, please click here to buy。

SET7: AL-DDB-Air Kit For Ender-3 OR Ender-3 PRO
*Ender-3 = Ender-3 pro (They are compatible with each other)
-24V AL-DDB-Air Kit                      X 1
-V6 NOZZLE 0.4MM/1.75MM          X 1
-V6 Heat Block                             X 1
-All Metal V6 Heat break               X 1
-fan                                            X 2
-Heating Cartridge (24V 40W)       X 1
-Thermistor cartridge (104GT-2)   X 1
-Thermistor cartridge(100K 3950) X 1
-Extra spare parts
-Aluminum Base Adapter

*You can continue to use your own stepper motor. You can also purchase our NEMA17 23MM stepper motor, please click here to buy。



▉AL-DDB-Air Dimensions

▉AL-DDB-Air Cooled KitList:
PETG printed parts:
5015_FAN_DUCT x1
5015_FAN_MOUNT_AC x1
AL-DDB_BLTOUCH_MOUNT x1
AL-DDB_M8SENSOR_MOUNT x1
AL-DDB_M12SENSOR_MOUNT STL file only
AL-DDB_M18SENSOR_MOUNT STL file only
5015_FAN_MOUNT_AC_volcano STL file only
AL-DDB_BLTOUCH_MOUNT_volcano STL file only

Injection Mold Plastic parts:

DDB extruder base x1
DDB extruder handle  x1
Machined parts:
AL-DDB Extruder Air Cooled body x1
Heater block AL x1
Nozzle brass 0.4 x1
Heat breaker full metal x1
Mechanical parts:
Gear shaft x1
Motor pinion gear x1
Filament drive gear one pair
5*8*2.5 Bearings x2
Φ3 Shaft L30MM x1
Φ3 Shaft L20MM x1
Fastener:
M3 nut x 5
Zip tie x 5
M2.5 self-tapping x 2
M3X10 x 5
M3x35 x 3
M3x20 x 2
M3 spring washer x 7
M2.5x16 x 2
M2x5 x 2
M2x8 x 2
Spring x 1
Thumb screw x 1
Nylon washer x 1
Electric:
5015 24/12V FAN  1meter wire and connectors x1
3010 24/12V FAN  1meter wire and connectors x1
Heater cartridge 12/24V 40W x1
Thermistor NTC100K B3950 x1
Thermistor 104GT-2 x1
Extension wire 1meter x1
*Nema17-23MM stepper motor x 1 (need to buy SET3 OR SET4)
Accessories:
4x2 PTFE TUBE L=34MM chamfered
4x2 PTFE TUBE L=100MM
shrink tube x8
Bowden tube collet x1
Collet clips x2
Allen key set x1
Optional:
M8 5V proximity sensor
TL-touch ABL sensor
Mounting plate kit for CR/Ender printers

*If you need Nema17-23 Stepper motor, please click here to buy.
*If you need 3D Touch Sensor,please click here to buy.
*If you need M8 Inductive Proximity Sensor, please click here to buy.

▉NOTE:

1 If you have extra stepper motors, please buy SET1 or SET2.
2 AL-DDB-Air supports 3D Touch Sensor and M8/M12/M18 inductive proximity sensor.
In this store you can buy 3D TOUCH SENSOR and M8 inductive proximity sensor .

▉Photo display:

Two different sensors are demonstrated in our photo. for reference only.
The 3D touch or M8 inductive proximity sensor is not included in the product. They need to be purchased separately.

Perfect installation demo:
▉Flexibility:
The accessories in the photo are for demonstration purposes only.
This accessory is not included in the product.
