23mm Stepper Motor

SKU:
Trianglelab tatan Stepper Motor 4-lead Nema 17 23mm 42 motor 3D printer extruder for J-head bowden reprap mk8
Limited Offer!
4.6 (5 Reviews)
78 Sold
$13.11 $11.41
-13%
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity
-
+
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
1/1
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
  • 23mm Stepper Motor
Frequently Bought Together
more
Frequently Bought Together
Credit Card Payment Notice If you want to pay by credit card or debit card (not PayPal), please click "check out" to enter the next page and fill in the complete and accurate delivery information.Then select the first one "Credit or Debit Cards" in the payment method.
Credit Card Payment Notice
  • Description
  • Before ordering, please note that all our products do not include tax, you need to declare your own tax!

  • If you need to send UPS/Fedex/TNT/DHL, please contact us. We need to discuss the freight with you.

  • Technical questions e-mail:[email protected]

  • Sales questions e-mail:[email protected]

  • The trianglelab has always been concerned about product quality.We are developing products and working hard to improve the quality.We will not abandon our reputation because of many cheap products on the market.It is believed that only high quality products can ensure the quality of your work and bring safety to your work.

  • Some of our products may be more expensive than others,but please believe in our quality and believe that you will not regret when you receive the goods.
    23MM TATAN Stepper Motor

▉About logistics description:
Because the package contains strong magnets, ordinary logistics cannot be transported. So no matter which kind of logistics you choose. We will modify the logistics you choose. The package will be transported by air transportation of special dangerous goods, or other logistics. We will ensure that your package arrives as soon as possible. Thanks for your trust.
If you did not choose a magnetic product. Then your transportation will not be changed to a magnetic transportation route.



1.8° NEMA17 23mm Ttan Stepper Motor

Specifications:

4-lead Nema 17 23mm tatan Stepper Motor
NEMA 17
Number of Phase 2
Step
Angle 1.8° deg.
Rated Voltage 5.5V
Rated Current/Phase 1A(Peak Value)
Phase Resistance 5.5Ω±10%(20℃)
Phase Inductance 6.7mH±20%(1kHz 1V RMS)
Holding Torque 2.0 kg
.cm
Insulation Class B(130℃)
Weight 0.15kg

Motor size

Motor wire



Specifications:

1.8° NEMA17 23mm Tatan Stepper Motor

NEMA 17
Number of Phase 2
Step Angle 1.8° deg.
Rated Voltage 5.5V
Rated Current/Phase 1A(Peak Value)
Phase Resistance 5.5Ω±10%(20℃)
Phase Inductance 6.7mH±20%(1kHz 1V RMS)
Holding Torque 2.0 kg.cm
Insulation Class B(130℃)
Weight 0.15kg


☺Product display
